Design
For connoisseurs of the
unconventional: Achieve fascinating looks with the styles of the DESIGN
collection. Unique, individual and bold – just like you. From ancient
maps and plans of Berlin to graffiti covered containers, no design trend
is overlooked in this collection.
| Test |
Characteristics |
Test method |
| Formaldehyde emission |
< 0,05 ppm |
EN 717-1 |
| Surface stain resistance |
Grade 5, no visible changes to surface |
EN 438-2, 15 |
| Lightfastness |
≥ Level 6 Blue Wool Scale
≥ Level 4 Grey Scale |
EN ISO 105-B02
EN 20 105-A02 |
| Resistance to cigarette embers |
Grade 4, no visible changes to surface |
EN 438-2, 18 |
| Fire resistance |
Ignites with difficulty, at least Cfl-s1 |
EN 13501-1 |
| Height difference between connected elements |
Average: ≤ 0,10 mm
max: ≤ 0,15 mm |
EN 13329 |
| Edge straightness (bend) |
≤ 0,3 mm/m |
EN 13329 |
| Openings between connected elements |
Average: ≤ 0,15 mm
max: ≤ 0,20 mm |
EN 13329 |
| Static indentation |
< 0,01 mm - no visible changes, Impression in test with straight steel cylinder of 11,3 mm diameter |
EN 433 |
Product Range
| Strength |
Lenght |
Width |
Panels per box |
m² / box |
Boxes per pallet |
m² / pallet |
| 8 |
644 |
31 |
10 |
0,200 |
48 |
9,583 |
| 8 |
1380 |
193 |
8 |
2,131 |
56 |
119,320 |
| 8 |
644 |
310 |
10 |
1,996 |
48 |
95,827 |
Surfaces
|
|
1-STAB |
|
Edges
Installation instructions „Express Clic System“
Installation
